| Biodiesel Capability | B20¹ |
|---|---|
| Bore | 4.13in |
| Displacement | 433.3in³ |
| Emissions | Meets U.S. EPA Tier 4 Final, EU Stage V emission standards. |
| Engine Model | Cat C7.1 |
| Engine Power - ISO 14396 | 275hp |
| Engine Power - ISO 14396 (DIN) | 279hp (metric) |
| Net Power - ISO 9249 | 271hp |
| Net Power - ISO 9249 (DIN) | 275hp (metric) |
| Note (1) | Net power advertised is the power available at the flywheel when the engine is equipped with fan, air intake system, exhaust system, and alternator with engine speed at 2,200 rpm. Advertised power is tested per the specified standard in effect at time of |
| Note (2) | ¹Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) and are compatible* with ULSD blended with the following lower-carbon intensity fuels** up to: 20% biodiesel FAME (fatty acid methyl ester)*** 100% |
| Stroke | 5.31in |
| Maximum Drawbar Pull | 66319lbf |
|---|---|
| Maximum Travel Speed | 3mile/h |
| Main System - Maximum Flow | 132.6gpm |
|---|---|
| Maximum Pressure - Equipment | 5076psi |
| Maximum Pressure - Equipment - Lift Mode | 5511psi |
| Maximum Pressure - Swing | 4061psi |
| Maximum Pressure - Travel | 5076psi |
| Maximum Swing Torque | 100308lbf·ft |
|---|---|
| Swing Speed | 8.1r/min |
| General Forestry | 83300lb |
|---|---|
| Log Loader (U/U) | 89290lb |
| Note (1) | 558 mm (22") Side Entry Cab (SEC) Riser, High Wide undercarriage, Reach boom, R2.95 m (9'8") Reach stick, 700 mm (28") double grouser shoes, no bucket. |
| Note (2) | 1219 mm (48") Rear Entry Cab (REC) Riser, High Wide undercarriage, Log Loader boom, 3.76 m (12'4") Under/Under stick with live heel, 700 mm (28") double grouser shoes, no grapple. |
| Cooling System | 10gal (US) |
|---|---|
| DEF Tank | 11gal (US) |
| Engine Oil | 7gal (US) |
| Final Drive - Each | 3gal (US) |
| Fuel Tank | 262gal (US) |
| Hydraulic System - Including Tank | 92gal (US) |
| Hydraulic Tank | 49gal (US) |
| Swing Drive | 4gal (US) |
| Counterweight Clearance | 4.9ft |
|---|---|
| Ground Clearance | 2.5ft |
| Handrail Height | 11.5ft |
| Length: General Forestry - Boom Stretched Out | 41.3ft |
| Length: Log Loader - Boom Stretched Out | 49.6ft |
| Note (1) | General Forestry |
| Shipping Height - Tilted Cab | 11.5ft |
| Tail Swing Radius | 11.6ft |
| Track Gauge | 9.2ft |
| Track Length | 16.6ft |
| Track Length to Center of Rollers | 13.2ft |
| Transport Width | 11.6ft |
| Max Reach at Grapple Mount on Heel at Ground Level - Log Loader Under/Under | 33.5ft |
|---|---|
| Max Reach at Stick Nose at Ground Level - General Forestry Road Builder | 29.5ft |
| Note (1) | The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 2.1 (22" Riser CAB)/2.2 (48"/72" Riser CAB) kg of refrigerant, which has a CO2 equivalent of 3.003 |
|---|
