Multi-Processors

Performance

Cycle Time - Open
1.8s
Cycle Time - Close
1.2s
Crushing Force - Primary Cutter
406Sh Ton
Crushing Force - Cutter Tip
187Sh Ton
Crushing Force - Tooth Tip
127Sh Ton

Recommended Carrier Weight

Excavator Minimum
24 tons
Excavator Maximum
35 tons

Hydraulic Requirements

Jaw Circuit - Max. Oil Pressure
5076psi
Jaw Circuit - Max. Oil Flow
225gal/min
Rotation Circuit - Max. Oil Pressure
2031psi
Rotation Circuit - Max. Oil Flow
40l/min

Dimensions - Jaw

Jaw Depth
753mm
Cutter Length
439mm
Jaw Opening - Maximum
826mm
Jaw Width - Fixed
14in
Jaw Width - Moveable
5in

Weight

Weight - Housing, Jaw and Bracket
5854lb
Weight - Jaw Only
2277lb

Standard Equipment:

Optional Equipment:
