| Bore | 4.1in |
|---|---|
| Displacement | 268.5in³ |
| Emissions | Meets Tier 4 Final/Stage IV emission standards. |
| Engine Model | Cat C4.4 with Twin Turbo |
| Engine Power - Maximum Gross - ISO 14396 | 117 kW (157 hp [159 hp]*) |
| Engine Power - Maximum Net - ISO 9249/SAE J1349 | 112 kW (150 hp [152 hp]*) |
| Maximum Torque - 1,400 rpm | 523ft·lbf |
| Net Power | 150HP |
| Note | *Metric values. |
| Number of Cylinders - In Line | 4 |
| Ratings | 1800r/min |
| Stroke | 5in |
| Maximum Travel Speed | 19mile/h |
|---|
| Maximum Swing Torque | 27289ft·lbf |
|---|---|
| Swing Speed | 8.1r/min |
| Drawbar Pull | 23380lbf |
|---|---|
| Maximum Forward/Reverse - 2nd Gear | 19mile/h |
| Maximum Gradeability (16 500 kg/36,380 lb) | 78% |
| Counterweight | 8267lb |
|---|---|
| Note | *Includes medium stick, counterweight, full fuel tank, operator, dual pneumatic tires. Weight varies depending on configuration. |
| Operating Weight* | 15 790 to 16 770 kg (34,811 to 36,972 lb) |
| VA Boom - Front Radial Dozer, Rear Outriggers | 36972lb |
| VA Boom - Rear Radial Dozer Only | 34811lb |
| Ground Clearance | 14.6in |
|---|
| Maximum Shipping Length - With Long Stick | 26.75ft |
|---|---|
| Maximum Width - With Parallel Blade | 8.33ft |
| Tail Swing Radius | 5.75ft |
| Maximum Flow - Auxiliary Circuit - High Pressure | 58gal/min |
|---|---|
| Maximum Flow - Auxiliary Circuit - Medium Pressure | 12.7gal/min |
| Maximum Flow - Implement/Travel Circuit | 58gal/min |
| Maximum Flow - Swing Mechanism | 18.5gal/min |
| Maximum Pressure - Auxiliary Circuit - High Pressure | 5076psi |
| Maximum Pressure - Auxiliary Circuit - Medium Pressure | 2683psi |
| Maximum Pressure - Implement Circuit - Heavy Lift | 5439psi |
| Maximum Pressure - Implement Circuit - Normal and Travel Circuit | 5076psi |
| Swing Mechanism | 4786psi |
| System | 64.7gal (US) |
| Diesel Exhaust Fluid Tank | 5gal (US) |
|---|---|
| Fuel Tank - Total Capacity | 77.9gal (US) |
| Note | Range values are calculated with GD bucket 1100 mm (43"), 0.68 m3 (0.89 yd3) with tips J250 and quick coupler with a tip radius of 1437 mm (56.6"). |
|---|---|
| VA Boom - 2300 mm (7'7") Stick Length: Digging Depth | 17.92ft |
| VA Boom - 2300 mm (7'7") Stick Length: Digging Height | 32.5ft |
| VA Boom - 2300 mm (7'7") Stick Length: Dump Height | 23.08ft |
| VA Boom - 2300 mm (7'7") Stick Length: Reach at Ground Level | 28.58ft |
| VA Boom - 2450 mm (8'0") Stick Length: Digging Depth | 18.25ft |
| VA Boom - 2450 mm (8'0") Stick Length: Digging Height | 32.08ft |
| VA Boom - 2450 mm (8'0") Stick Length: Dump Height | 22.75ft |
| VA Boom - 2450 mm (8'0") Stick Length: Reach at Ground Level | 28.67ft |
