| Bore | 5.7in |
|---|---|
| Desplazamiento | 1105 pulg. |
| Emisiones | Einhaltung von EPA Tier 4 Final (USA)/Stufe V (EU), Tier-2-konform |
| Modelo de motor | Cat® C18 ™ |
| Gross - ISO 14396 | 580HP |
| Poder de la red | 541HP |
| Net Power - SAE J1349 | 541HP |
| Peak Power Speed | 1500/min |
| Peak Power Speed - 1,500 rpm - Gross - ISO 14396 | 580HP |
| Peak Power Speed - 1,500 rpm - Gross - SAE J1995 | 588HP |
| Peak Power Speed - 1,500 rpm - Net Power - SAE J1349 | 541HP |
| Peak Torque - 1,200 rpm | 2104lb/ft |
| Velocidad nominal | 1700/min |
| Golpe | 7.2in |
| Aumento del par de torsión | 58% |
| Bucket Capacity Range | 6.4-7.6 m3 (8.3-10 yd3) |
|---|---|
| Cat Truck Match - High Lift | 773-775 |
| Cat Truck Match - Standard | 770-772 |
| Peso operativo | 112574lb |
| Carga útil nominal | 12.5t |
| Rated Payload - High Lift | 12.5t |
| Rated Payload - Standard | 12.5t |
| Capacidades de los cubos | 5,4-6,3 m3 (7,0-8,3 yd3) |
|---|
| Direct Drive - Forward 1 | Lock-up disabled |
|---|---|
| Direct Drive - Forward 2 | 7.8 millas/h |
| Direct Drive - Forward 3 | 13.9mile/h |
| Direct Drive - Forward 4 | 24.4mile/h |
| Direct Drive - Reverse 1 | 5 millas/h |
| Direct Drive - Reverse 2 | 8.9 millas/h |
| Direct Drive - Reverse 3 | 15.8mile/h |
| Adelante - 1 | 4mile/h |
| Adelante - 2 | 7.2mile/h |
| Adelante - 3 | 12.7mile/h |
| Adelante - 4 | 21.6mile/h |
| Reverso - 1 | 4.7mile/h |
| Reverso - 2 | 8.3mile/h |
| Reverso - 3 | 14.4mile/h |
| Transmission Type | Cat-Planetenlastschaltgetriebe |
| Front | Fijo |
|---|---|
| Oscillation Angle | ±6° |
| Rear | Trunnion |
| Flujo máximo | 71.3gal/min |
|---|---|
| Relief Valve Setting - Steering | 4351psi |
| Steering Cycle Times - High Idle | 3.4s |
| Steering Cycle Times - Low Idle | 5.6s |
| Steering System - Circuit | Pilot, load sensing |
| Steering System - Pump | Piston, variable displacement |
| Total Steering Angle | 80° |
| Sistema de refrigeración | 31.7gal (US) |
|---|---|
| Cárter | 15.9gal (US) |
| Diesel Exhaust Fluid Tank (Tier 4) | 8.7gal (US) |
| Diferencial - Final Drives - Frontal | 49.1gal (US) |
| Diferencial - Accionamientos finales - Trasero | 49.1gal (US) |
| Tanque de combustible | 181gal (US) |
| Hydraulic System - Tank Only | 63.4gal (US) |
| Hydraulic System Factory Fill | 125.5gal (US) |
| Transmisión | 31.7gal (US) |
| Cylinders, Double Acting - Lift, Bore and Stroke | 210 mm × 1050 mm (8.3 in × 41.3 in) |
|---|---|
| Cylinders, Double Acting - Tilt, Bore and Stroke | 267 mm × 685 mm (10.5 in × 27.0 in) |
| Lift/Tilt System | Pistón de desplazamiento variable |
| Lift/Tilt System - Circuit | EH- Positive Flow Control, Flow Sharing |
| Flujo máximo | 13.7gal/min |
| Maximum Flow at 1,400-1,860 rpm | 153gal/min |
| Pilot System | Pistón de desplazamiento variable |
| Relief Valve Setting - Lift/Tilt | 4757psi |
| Relief Valve Setting - Main | 551psi |
| Dump | 2.2s |
|---|---|
| Lower Float Down | 3.5s |
| Rack Back | 4.5s |
| Raise | 8s |
| Total Hydraulic Cycle Time - Empty Bucket | 18.2s |
| Machine Sound Level (ISO 6395) | 111dB(A) |
|---|---|
| Operator Sound Level (ISO 6396) | 71dB(A) |
| Machine Sound Level (ISO 6395) | 109dB(A) |
|---|---|
| Operator Sound Level (ISO 6396) | 70dB(A) |
| Frenos | SAE J1473 OKT90, ISO 3450:1992 |
|---|
