Bore | 5.1in |
---|---|
Desplazamiento | 680in³ |
Modelo de motor | Cat® C11 |
Engine Power - Tier 3 Engine - ISO 14396:2002 | 345HP |
Engine Power - VR Engine - ISO 14396:2002 | 345HP |
Nota (1) | Power ratings apply at a rated speed of 1,800 rpm when tested under the reference conditions for the specified standard. |
Nota (2) | All rating conditions are based on ISO/TR 14396, inlet air standard conditions with a total barometric pressure of 100 kPa (29.5 in Hg), with a vapor pressure of 1 kPa (.295 in Hg), and 25° C (77° F). Performance measured using fuel to EPA specifications |
Nota (3) | Engine derate will commence at an altitude of 3050 m (10,006 ft). |
Nota (4) | Optional Ventilation Reduction package available. |
Note (5) | Optional engine with emissions equivalent to U.S. EPA Tier 3 and EU stage IIIA is also available. |
Golpe | 5.5in |
Breakout Force - SAE | 46051lb |
---|---|
Gross Machine Mass - Tramming | 120151lb |
Gross Machine Mass - Truck Loading | 116845lb |
Capacidad de carga nominal | 27558lb |
Nominal Payload Capacity - Tramming | 30865lb |
Nominal Payload Capacity - Truck Loading | 27558lb |
Static Tipping Load - Full Turn - Lift Arms Horizontal | 57995lb |
Static Tipping Load - Straight Ahead - Lift Arms Horizontal | 70065lb |
Empty | 84878lb |
---|---|
Empty - Front Axle | 37346lb |
Empty - Rear Axle | 47532lb |
Loaded | 112436lb |
Loaded - Front Axle | 81741lb |
Loaded - Rear Axle | 30695lb |
Loaded - Tramming | 115743lb |
Dump | 2.9s |
---|---|
Lower, Empty, Float Down | 2.4s |
Raise | 6.8s |
Total Cycle Time | 12.1s |
Capacidad del cubo | 4.6-8.8 m³ (6.0-11.5 yd³) |
---|---|
Dump Bucket - 1 | 6yd³ |
Dump Bucket - 2 | 6.5yd³ |
Dump Bucket - 3 - Standard Bucket | 7.5yd³ |
Dump Bucket - 4 | 8.6yd³ |
Dump Bucket - 5 | 9.5yd³ |
Dump Bucket - 6 | 11.5yd³ |
Ejector Bucket | 7.5yd³ |
Articulation Angle | 44° |
---|---|
Axle Oscillation | 8° |
Inner Clearance Radius** | 127.1in |
Nota | **Clearance Dimensions are for reference only. |
Outside Clearance Radius** | 270.8in |
Sistema de refrigeración | 16.6gal (US) |
---|---|
Engine Crankcase - With Filter | 8.98gal (US) |
Front Differential and Final Drives | 23.8gal (US) |
Tanque de combustible | 150.3gal (US) |
Tanque hidráulico | 33gal (US) |
Rear Differential and Final Drives | 23.8gal (US) |
Secondary Fuel Tank - If Equipped | 117.8gal (US) |
Transmisión | 12.4gal (US) |
Adelante - 1 | 2.9 millas/h |
---|---|
Adelante - 2 | 5.2 millas/h |
Adelante - 3 | 8.9 millas/h |
Adelante - 4 | 15 millas/h |
Reverso - 1 | 3.4 millas/h |
Reverso - 2 | 5.8mile/h |
Reverso - 3 | 10.2mile/h |
Reverso - 4 | 15.7 millas/h |
Tire Size | 26.5 × 25 |
---|
Estándares | ROPS/FOPS Certified Cab |
---|
