El suelo de la barra de seguridad del VT SE50

Back to Home

The SE50 VT is a Tamper bar screed that is equipped with rear-mounted extenders and vibratory screed plates. It offers a standard extendable paving range of 2.55 – 5.0 m (8′ 4″ – 16′ 4″) and excels on highways, parking lots, urban streets and other variable width paving applications.

Request a quote
Peso estándar 7363lb
Crown Range -2% to +5%
Extender Height Range -20 mm to +50 mm
Extender Slope Range -3% to +2%
Heating Time - Maximum Width 25 minutes
Heating Time - Standard Width 15 minutes
Maximum Paving Depth 12in
Máximo rango de pavimentación 26,3 pies
Rango de pavimentación estándar 2.55 - 5.0 m (8' 4" - 16' 4")
Tamper Speed Range 700 to 1800 rpm
Vibrator Speed Range 0 to 3000 rpm
Length - Front to Back, Endgates Attached 92in
Length - Front to Back, Endgates Removed 68in
Screed Plate Width - Front to Back 12.75in
Transport Length - Tractor and Screed 22.1ft
Transport Width - Endgates Folded 8,33 pies
