Bore | 4.1in |
---|---|
Desplazamiento | 268.5in³ |
Emisiones | Meets Tier 4 Final/Stage IV emission standards. |
Modelo de motor | Gato C4.4 con Twin Turbo |
Engine Power - Maximum Gross - ISO 14396 | 117 kW (157 hp [159 hp]*) |
Engine Power - Maximum Net - ISO 9249/SAE J1349 | 112 kW (150 hp [152 hp]*) |
Par máximo - 1.400 rpm | 523ft·lbf |
Poder de la red | 150HP |
Nota | *Valores métricos. |
Number of Cylinders - In Line | 4 |
Calificaciones | 1800r/min |
Golpe | 5in |
Velocidad máxima de viaje | 19 millas/h |
---|
Par de giro máximo | 27289ft·lbf |
---|---|
Velocidad de giro | 9r/min |
Drawbar Pull | 23380lbf |
---|---|
Maximum Forward/Reverse - 2nd Gear | 19 millas/h |
Maximum Gradeability (17 500 kg/38,580 lb) | 70% |
Contrapeso | 9480lb |
---|---|
Nota | *Includes medium stick, counterweight, full fuel tank, operator, dual pneumatic tires. Weight varies depending on configuration. |
Operating Weight* | 16 750 to 17 750 kg (36,927 to 38,691 lb) |
VA Boom - Front Dozer, Rear Outriggers | 38691lb |
VA Boom - Rear Dozer Only | 36927lb |
Despeje del terreno | 14.6in |
---|
Maximum Shipping Length - With Long Stick | 27.75ft |
---|---|
Maximum Width - With Parallel Blade | 8,33 pies |
Radio de giro de la cola | 5.83ft |
Maximum Flow - Auxiliary Circuit - High Pressure | 58gal/min |
---|---|
Maximum Flow - Auxiliary Circuit - Medium Pressure | 12.7gal/min |
Maximum Flow - Implement/Travel Circuit | 58gal/min |
Maximum Flow - Swing Mechanism | 18.5gal/min |
Maximum Pressure - Auxiliary Circuit - High Pressure | 5076psi |
Maximum Pressure - Auxiliary Circuit - Medium Pressure | 2683psi |
Maximum Pressure - Implement Circuit - Heavy Lift | 5439psi |
Maximum Pressure - Implement Circuit - Normal and Travel Circuit | 5076psi |
Mecanismo de balanceo | 4786psi |
System | 64.7gal (US) |
Depósito de líquido de escape diesel | 5gal (US) |
---|---|
Fuel Tank - Total Capacity | 77.9gal (US) |
Nota | Range values are calculated with GD bucket 1100 mm (3'7"), 0.80 m3 (1.05 yd3) with tips K080 and quick coupler with a tip radius of 1574 mm (5'2"). |
---|---|
VA Boom - 2450 mm (8'0") Stick Length: Digging Depth | 18.67ft |
VA Boom - 2450 mm (8'0") Stick Length: Digging Height | 32.5ft |
VA Boom - 2450 mm (8'0") Stick Length: Dump Height | 22.33ft |
VA Boom - 2450 mm (8'0") Stick Length: Reach at Ground Level | 29.08ft |
VA Boom - 2600 mm (8'6") Stick Length: Digging Depth | 19.25ft |
VA Boom - 2600 mm (8'6") Stick Length: Digging Height | 33.58ft |
VA Boom - 2600 mm (8'6") Stick Length: Dump Height | 23.33ft |
VA Boom - 2600 mm (8'6") Stick Length: Reach at Ground Level | 29.92ft |
