General Appearance

Cleaning Required

No

S.O.S. Taken

Yes

Cab or Canopy

Good

Draw Bar

Good

Fuel Tank

Good

Grab Irons

Good

Hood

Good

Main Frame Welds

Good

Paint

Good

Sheet Metal

Good

Steps / Ladder

Good

Safety Items

ROPS

Yes

Back Up Alarm

Good

Horn

Good

Parking Brake - SAFETY ITEMS

Good

Gauges, Operator Station, Console

Current O&MM

Yes

Current Safety Manual

Yes

Air Conditioner

Good

Dash Console

Good

EMS Panel / Warnings

Good

Gauges

Good

Glass/Mirrors

Good

Heater

Good

Interior Lights

Good

Seat Cushion / Arm Rest

Good

Switches

Good

Windshield Wipers

Good

Engine

Blow By

No

Compression in Radiator

No

Fluid Levels OK?

Yes

Knocking

No

Oil Leaks

No

Water in Oil

No

Engine Supports

Good

Fuel Injection System

Good

Operating Condition - ENGINE

Good

Turbocharger / Blower

Good

Cooling System

Leaks - COOLING SYSTEM

No

Standard Radiator

Yes

Belts / Pulleys - COOLING SYSTEM

Good

Coolers

Good

Fan

Good

Hoses

Good

Radiator

Good

Water Pump

Good

Electrical, Starting And Charging System

Alternator

Good

Batteries / Cables

Good

Starter

Good

Wiring

Good

Transmission

Leaks - TRANSMISSION

No

Transmission - Noisy

No

Controls - TRANSMISSION

Good

Cooler

Good

Lines / Fittings - TRANSMISSION

Good

Operating Condition - TRANSMISSION

Good

Pump - TRANSMISSION

Good

Temp / Pressure Gauges

Good

Transmission - Forward Shifts

Good

Transmission - Reverse Shifts

Good

Steering

Steering Linkage

Good

Steering Operating Condition

Good

Hydraulics

Leaks - HYDRAULICS

No

Angle Cylinder

Good

Control Linkage - HYDRAULICS

Good

Hose Lines

Good

Lift Cylinders

Good

Overall Operating Condition

Good

Tilt Cylinder

Good

Blade

Cutting Edge & Bits

Good

Face / Moldboard

Fair

Pins

Fair

Tower

Good

Trunnions

Fair

Undercarriage

Pins & Bushings Turned?

No

Track Frame - Left

Good

Track Frame - Right

Good

Carrier Rollers Front

Left: 144 Measurement, Left: 70% Worn, Right: 146 Measurement, Right: 60% Worn

Idlers Front

Left: 19 Measurement, Left: 32% Worn, Right: 19 Measurement, Right: 32% Worn

Links

Left: 1% Worn, Right: 1% Worn

Pins & Bushings (External)

Left: 1% Worn, Right: 1% Worn

Segments

Left: 1% Worn, Right: 1% Worn

Track Roller 1

Left: 18 Measurement, Left: 60% Worn, Right: 18 Measurement, Right: 60% Worn

Track Roller 2

Left: 17 Measurement, Left: 50% Worn, Right: 17 Measurement, Right: 50% Worn

Track Roller 3

Left: 17 Measurement, Left: 50% Worn, Right: 17 Measurement, Right: 50% Worn

Track Roller 4

Left: 17 Measurement, Left: 50% Worn, Right: 17 Measurement, Right: 50% Worn

Track Roller 5

Left: 17 Measurement, Left: 50% Worn, Right: 17 Measurement, Right: 50% Worn

Track Roller 6

Left: 17 Measurement, Left: 50% Worn, Right: 17 Measurement, Right: 50% Worn

Track Roller 7

Left: / Measurement, Right: / Measurement

Final Drives

Housings, Left

Good

Housings, Right

Good

Planetaries / Differential, Left

Good

Planetaries / Differential, Right

Good
